21.5" Dual Color Strobe Curved Light Bar
This 21.5" Dual Color Strobe Curved Light Bar is dustproof, shockproof and waterproof IP68, make you driving safer in the dark and raining day. This 21.5" Dual Color Strobe Curved Light Bar has 40 patterns, easy control with the wireless remote. The 21.5" Dual Color Strobe Curved Light Bar fit for all kinds of vehicles, such as Jeep, truck, ATV, UTV, 4x4, Cars, Motorcycles,Boats and can also be used for industrial lighting, marine lighting, auxiliary Lights, and tractor lighting.
Power / Output Specifications:
- Power Rating: 120w
- Voltage: 10v-30v
- Total Lumen Output: 9000LM
Features:
- Dimensions: height 3.15'' x depth 3.54''
- Dimensions: 21.5 inch
- Optional Beam: Combo Beam (spot in the middle, flood at both sides)
- Emitting Color: White/Red, White/Green, White/Blue, White/Amber, Red/Blue, etc.
- Color Temperature: 6000K
- Lens Material: PC
- Material: Diecast aluminum housing
- Mounting Bracket: Alu firm bracket
- Waterproof Rate: IP 68
- Lifespan: >30,000hrs
- Warranty: 2 Years warranty
About Brake/Turn Signal Line
This Brake/Turn Signal Line has 3 wires, which will have different flash effects when touch with positive wire.
Black Line for Right Turn;
Yellow Line for Left Turn;
Red Line for Brake.
What’s Included:
- 1x 21.5" Dual Color Strobe Curved Light Bar
- Universal Mounting Brackets
- 1x Wireless Remote Controller or 1x pre-wired controller
If you have any questions about the 21.5" Dual Color Strobe Curved Light Bar, please feel free to contact us!
QUESTIONS & ANSWERS
Have a Question?
-
red/blue light, does it switch to white or is it only red/blue?
I 'm sorry , if you choose red/blue, it can switch only red /blue light .no white .
-
Does the color changing light bar have alternating flash pattern along with just a solid white? The switch controller allows the pattern to change by hitting the red button on the controller? I am looking for a light that is solid white to assist for night driving and also a light that flashes red/white for fire response to help notify traffic of an emergency vehicle.
1.The color changing light bar doesn't have alternating flash pattern,but it has 9 flash patterns and solid white/red.
2.Yes,it changes pattern by hitting red button
3.If you choosed red/white then it is not only solid white/red,but also strobe 9 flash patterns -
If I get a RGB will it still be ran off the little wireless remote ?
Hi, Dear, this is Dual Color strobe light, it is controlled by a remote control, but if you Add RGB Halo, main LED will be controlled by remote controller, RGB halo will be controlled by Bluetooth APP.
-
What are the dimensions from hole to hole on the mounting brackets when installing? I know the light bar is 21.5 in, but when the mounting brackets are on the light, what is total distance between mounting holes.
Hello, the distance from mounting hole to the other mounting hole for 21.5" light bar is 61 cm.
-
would this fit in the bumper of a 2018 ram 3500? Leaving the tow hooks and using the brackets that convert to a 22" bar?
Hello, friend, we offer universal mounting brackets when you take 21.5" light bar and it will increase about 5cm when installing with the mounting brackets. You might need to find professional service or to buy proper mount brackets for your 2018 ram 3500.
-
So the custom control wiring is the red for the white and the black negative and the other 2 control the left and right side secondary color?
hi, thank you for your inquiry. There are four wires on the control box, two wires go to the positive and negative power wires, and the others go to the signal wires to control the color.
